Advanced Impact Testing Machine for Rigid Plastic & Nylon Toughness | High Precision Charpy & Izod Tester for Laboratory Quality Control
Product Description:
This impact tester is a high-performance laboratory instrument designed to evaluate the impact strength, toughness, and fracture resistance of rigid plastics and nylon materials. It utilizes advanced pendulum force control technology to provide consistent and accurate test results, helping engineers and researchers understand how materials behave under real-world impact forces. Whether used in quality control, R&D labs, or production validation, this instrument ensures your product's reliability and durability are demonstrated in every test.
International Test Standards:
- ISO 179-1:Determination of Charpy impact properties for plastics
- ISO 180:Determination of Izod impact strength for plastics
- ASTM D256:Izod Pendulum Impact Resistance of Plastics
Technical parameters:
| Item | XJJ-5 | XJJY-5 | XJJ-50 | XJJY-50 |
| The release way of controlling | electronic control | electronic control | electronic control | electronic control |
| The numerical value displayed | Pointer | Digital display | Pointer | Digital display |
| The energy of the pendulum bob( J) | 1, 2,4, 5 | 1, 2,4,5 | 7.5,15,25, 50 | 7.5, 15, 25,50 |
| The moment of the pendulum bob (N.M) | 1J PL=0.516,
2J PL=1.031,
4J PL=2.062,
5J PL=2.578 | 1J PL=0.516,
2J PL=1.031,
4J PL=2.062,
5J PL=2.578 | 7.5J PL=3.866 ,
15J PL=7.733,
25J PL=12.889,
50J PL=25.777 | 7.5J PL=3.866 ,
15J PL=7.733,
25J PL=12.889,
50J PL=25.777 |
| Min seale mark | 1/100 | 1/100 | 1/100 | 1/100 |
| Impact speed m/s | 2.9 | 2.9 | 3.8 | 3.8 |
| The pre-elevation of the pendulum bob | 160° | 160° | 160° | 160° |
| The distance from the pendulum shaft center to the sample center(mm) | 221 | 221 | 380 | 380 |
| The fillet radius of the jaw(mm) | 1 | 1 | 1 | 1 |
| The angle of the impact blade | 30° | 30° | 30° | 30° |
| The fillet radius of the impact blade | 2mm | 2mm | 2mm | 2mm |
| The weight of the machine base | It is more than 40 times of the heaviest pendulum bob and it can be adjusted to the horizontal station | It is more than 40 times of the heaviest pendulum bob and it can be adjusted to the horizontal station | It is more than 40 times of the heaviest pendulum bob and it can be adjusted to the horizontal station | It is more than 40 times of the heaviest pendulum bob and it can be adjusted to the horizontal station |
| Power supply | 220V/50HZ | 220V/50HZ | 220V/50HZ | 220V/50HZ |
| The sample type | length C | Width B | Thickness D | offset distance |
| Ⅰ | 80 | 10 | 4 | 60/62 |
| Ⅱ | 50 | 6 | 4 | 40 |
| Ⅲ | 120 | 15 | 10 | 70 |
| Ⅳ | 125 | 13 | 13 | 95 |
Typical Applications:
- Plastic and polymer material research laboratories
- Quality control departments in manufacturing plants
- Educational and research institutions
- Automotive, aerospace, and electrical component testing
- Nylon and engineering plastic product factories
Product photos:
Why Choose HONG CE?
- 100% in-house R&D and manufacturing
- Over 15 years of expertise in material testing
- rusted by global laboratories and certification centers
- CE-certified and ISO-compliant production system
- Tailored OEM/ODM solutions for testing projects
About us:
HongCe Equipment Co., Ltd, located in Guangdong, China, has been a key player in the inspection equipment business since 2012. We brought in advanced equipment and use leading technology in our production. We also have a strict quality control system during the process.
We have a team of tech-savvy managers, plus modern management and computer-aided design, so our products are up to global standards. We handle everything from R&D and design to production and sales. We focus on making equipment for testing electric wires, plugs, sockets, electronic devices' durability, fire safety, shock resistance, and protection against foreign objects, along with general and custom testing equipment. Our products are popular both in China and internationally, and we supply several well-known companies.
